This kit allows you to install a Warn winch inside the factory bumper on a 2014-2018 Ram 2500 and 2013-2018 Ram 3500. This is an industry first, and finally provides a secure and tucked away winch mounting solution for Cummins Diesel Ram owners! If you've been looking for a way to neatly mount a winch on your truck, look no further. The best part? This kit is built in North America (Canada to be exact) so you can trust the workmanship and build quality.
This kit Requires a Warn VR EVO Control Box Relocation Kit which positions the control box in the engine with a specialty bracket and includes a new power harness. We include this with the winch kit option.
Want to add a color matched Factor 55 winch hook link; Click here.
This kit is not compatible with 2010-2012 Cummins equipped trucks because it uses a different intercooler. This is also NOT compatible with a CJC Skid plate.
FEATURES:
This kit is constructed from North American 1/4" HRPO A36 Plate Steel. The feet forward mounted winching platform is the strongest platform without adding a ton of weight. The design ties directly into the oversized front Tow Hook and bumper mounting hardware, and an Integrated hook mount means no rattles or scratched paint. The entire kit is powder coated a durable black finish.
Installation is straightforward with no drilling needed, but does require you to trim your plastic bumper insert. Alternatively you can also use the Power Wagon insert to avoid cutting.
WHAT THIS KIT INCLUDES:
- Upgraded Bumper Mounting Brackets
- Heavy Duty Winch Mounting System
- Integrated Hook Mounting Kit
- Complete Hardware Kit
- Detailed Instructions
WHAT WINCH IS COMPATIBLE:
We have designed this kit specifically around the WARN VR EVO Series of Winches. Why?
Strongest pulling power and largest motor for medium body winches
clutch handle is clockable and easy to access
control box is compact and easily relocated to the engine bay with our Control Box Relocation Kit
IP68 Waterproof rating. Ready for all environments.
Includes a high quality Wireless controller.
Most user friendly winch we've ever used.
Reliability, we've sold over 500 and only had 1 warranty to process.
Affordability. Undeniably the best value out there.
Comes with either Synthetic Rope [12-s, 103255] or Steel Cable [12, 103254]
Due to space constraints, this kit is not compatible with any other 12,000 lbs winch models. We will continue to explore other brands, but at this time we can only guarantee the fit with the WARN VR EVO 10, 10-s, 12, and 12-s models.
FITMENT:
This bracket kit is compatible with 2019, 2020, 2021, 2022, 2023 and; 2024 RAM 2500 and; 3500 trucks equipped with the 6.7L Cummins Turbo Diesel Engines
If you have a 6.4 HEMI truck, email us and we can get a the bracket kit compatible with your truck.
