The Carli 3500 Back Country level system pairs soft ride Carli front leveling height 2.5" lift coils with Carli's custom SPEC series 2.0 reservoir shocks. The result is a huge improvement in ride on and off road, and increased control when loaded. Paired with the included track bar, this is the proper way to level your 3500!
The Backcountry 2.0 system is designed for people seeking the best ride on and off-road quality on a budget; basically, the Leveling Kit for those that want to have a little dirt-road fun in their 8,500lb truck without losing the on-road ride quality or usability for which the truck was designed. You’re no longer limited to the highway while gravel roads become uninteresting as you can drive them at speed with one hand on the wheel. The 2.5” lift height doesn’t require the front or rear geometry correction of our 3” Systems.
Utilizing Carli SPEC 2.0″ Diameter, Remote Reservoir shocks, we’ve developed a tune that delivers all around comfort and ride quality designed for on-road, in town, highway, towing/hauling as well as slow to mid speed off road use. The remote reservoir Carli SPEC 2.0 boasts 6063 Aluminum construction, anodized body for corrosion resistance, 5/8″ hardened steel chrome plated shaft, full serviceability & rebuildability and are built with 1-peice bushings in the 6061 billet rod-ends. These shocks are spec’d with a premium 5WT oil to balance lubricity, consistent damping and the widest available range in temperature variation. We back these with a 1-year warranty, serviced by Carli.
The rear shocks are also included with this system and have been custom tuned to maximize the ride quality for the factory rear coil springs. As the rear springs remain unmodified, load capacity is maintained while predictability is improved. For those that aren’t looking for massive increase in travel or big shocks but still desire a level stance and improved ride quality and handling characteristics, on and off-road, this is the perfect kit.
Ram lowered single rear wheel 2019+ trucks, so that system incudes a 1" billet rear block and U-bolts. Dually and 13-18 systems do not include this billet block and U-bolt kit.
**This system will NOT be upgradeable to any other Carli Suspension Systems aside from the pintop level.** It’s designed to be a solution for customers wanting a quality system with minimal lift and part inclusion. This system is NOT compatible with trucks equipped with the factory auto-leveling air assist. For factory air trucks, we recommend this purpose built system. This system is not compatible with cab and chassis model trucks.
Front Lift | Rear Lift | Front Travel | Rear Travel | Shock Diameter | Tire Fitment |
---|---|---|---|---|---|
2.5″ | 1″ | 8.3″ | 11″ | 2.0″ | 35″ x 12.5″ |
