Carli's focus in building this control arm kit was to have the best product on the market. Carli's control arms are 1/2" longer than O.E.M and are built out of extremely stout box tubing. The box tubing's advantages over round tubing include a reduced control arm width while allowing the tube to be offset inboard for added tire clearance. Expertly welded to each square tube is a spherical joint that is fully serviceable and rebuildable. Having these spherical joints on each end eliminates the kinetic chatter caused by rubber bushing style set ups, in return creating a smoother ride. These control arms are finished off with a Satin Black powder coat to ensure long term protection from corrosion.
SPECIFICATIONS
-Box Tube Construction
-Maximum Tire Clearance
-Hardened Steel Joints
-Zirc Fittings For Easy Maintenance
-Manufactured In-House at Carli Suspension
-Sold as a set of 4 (2 upper, 2 lower)
FITMENT GUIDE
Year Model Part Number
1994-99 DODGE RAM 2500/3500 4x4 CS-CA-MS14-94
2000-02 DODGE RAM 2500/3500 4x4 CS-CA-MS16-94
*On 1994-2002 trucks, we recommend you check the bolt size to ensure the correct arms are purchased. We recommend taking a 14mm wrench and putting the open end against the threads of the lower control arm bolts. If it matches, the 14mm arms are the correct arms to order. If the bolt size is bigger than the open end of the wrench, the 16mm arms are the correct arms. If you have any questions in regards to this process, feel free to give us a call!
